PS Audio Aspen FR20 (sæt)

På lager
175.000 DKK
Leveringstid:7-8 uger

Den banebrydende Aspen-serie af højttalere sætter nye standarder for, hvad der er muligt i hjemmelydgengivelse. Med introduktionen af ​​den mindre FR20, er det endelig muligt, at bringe Aspens magi ind i flere menneskers hjem.

  • Gratis fragt over 500 DKK
  • Lagervarer sendes indenfor 24 timer
  • Afhentning i butik

Den perfekte størrelse højttaler til ethvert rum!

Den banebrydende Aspen-serie af højttalere sætter nye standarder for, hvad der er muligt i hjemmelydgengivelse. Med introduktionen af ​​den mindre FR20, er det endelig muligt, at bringe Aspens magi ind i flere menneskers hjem.

Aspen FR20 repræsenterer kulminationen på 50 års brancheerfaring; læren af detaljer, hvad der virker og hvad der ikke gør; hvad der skal til for at en højttaler forsvinder og kun efterlader musikkens magi - design af et kompromisløst fasekorrekt delefilter - at konstruere et kabinet, der ikke farver lyden - laver en næsten flad impedanskurve til at drive højttalerne med en hvilken som helst effektforstærker, og når ikke engang den mest avancerede driverproducents produkter er gode nok til at opfylde vores krævende standarder, designe basenheder, diskanthøjttalere og mellemtoner fra bunden.

Betagende at lytte til, smuk at se og kompatibel med enhver rumstørrelse, er Aspen FR20 en drøm, der går i opfyldelse.




** FEATURES **
FULL RANGE 3-WAY SYSTEM
ONE 2.5" PLANAR RIBBON TWEETER
TWO 8" LOW DISTORTION HIGH EXCURSION WOOFERS
10" PLANAR RIBBON MIDRANGE
TWO 10" LOW DISTORTION HIGH EXCURSION BASS RADIATORS
THERMOSET FIBERGLASS RESIN FRONT BAFFLES
ADVANCED CARBON FIBER PMI FOAM COMPOSITE WOOFER CONES
FLAT IMPEDANCE CURVE FOR EASY AMPLIFIER LOAD
IN-ROOM BASS RESPONSE TO 20hz @ -6db
ADJUSTABLE MILLED BRASS FEET
HEAVY INTERNAL BRACING FOR LOW CABINET VIBRATION
87 dB SENSITIVITY
SMOOTH AND FULL OFF AXIS RESPONSE
ONE PIECE CABINET FOR EASY SETUP
EASY TO POSITION FOR BEST PERFORMANCE
CUSTOM FILM CAPACITORS & PREMIUM AIR-CORE INDUCTORS

Design
Designing and building a new loudspeaker is both the easiest and hardest engineering challenge in all of high-fidelity. On the one hand, anyone can go online and buy a few drivers and bang together a box to make decent sound. On the other hand, the most difficult task in all of high-performance audio is crafting a seamless phase-correct output from two or more driver technologies. Over nearly a century of loudspeaker designs, few models have ever achieved legendary status. The FR20 joins the ranks of a rare handful of true full-range speakers that can honestly cover the frequency range of 28Hz to beyond 20kHz with grace, dynamics, slam, and low distortion. What's captured on the disc is exactly what you'll hear with a greater resolution than most have ever experienced. Grace, beauty, PRaT, power, and a musicality that is rare amongst 6 figure offerings from other manufacturers await owners of the aspen FR20. That this speaker is financially within reach of many makes it a miracle.

Application
Loudspeakers are part of the family. With their presence, they grace our homes and living areas by bringing the joy of music into our lives. Unlike the electronics that drive them, to perform their best most loudspeakers depend on proper placement and optimized room parameters. The aspen FR20, however, is designed to more easily fit into any living environment and perform at their best with a minimum of setup hassles and a maximum of options. While the FR20, like all high-performance speakers, appreciates some breathing room between them and the front wall, placement in the room for best performance is a snap. Using the included step-by-step guide and CD, setup, from unboxing to playing music, happens easily in a few short hours.

Technology
By far the most important piece in the HiFi chain is the loudspeaker. If the speaker cannot reproduce what's it is fed from the electronic chain, the missing musical information is forever lost. To achieve all that music demands, over the years loudspeaker designers have tried to leverage every trick in the book: electrostats for details, conventional drivers for dynamics, planars for transparency, ribbons, domes, horns, open baffles, bipoles, dipoles. The list is endless and the choices and their inevitable sonic compromises daunting. With close to 50 years under our collective belts, we at PS Audio determined to design the perfect loudspeaker. Our strategy would be to combine the best of all possible driver and crossover technologies in a single coherent design. We would call it the FR30 and we would follow it up with a smaller model, the FR20. Both would have unquestioned dynamics. They would be full range and capable of being driven by just about any amplifier. Their high-frequency drivers would have lower mass than the air they were driving and the speed and clarity of the best electrostats. Their midrange driver would be so transparent and uncolored as to be unnoticeable. And our speakers would never be shy when it came to the low end. With the FR20's 4 woofers per pair of speakers supported by 4 high-compliance passive radiators, in-room bass response would be nothing short of legendary.

The Enclosure
Loudspeakers have an honored place in our homes. They often are the focal point of our living rooms and in that capacity must proudly make a statement of fitting elegance. The aspen FR20 enclosure design starts with the internal structure necessary for great sound and then lovingly sculpted into a work of art befitting our homes. With industrial design by famed Studio 63, the FR20 stands as a proud sculpture comfortable in almost every decor. Internally, the FR20 is an extensively braced enclosure designed to minimize external vibrations that have the potential of coloring the sound. Externally, the enclosures are lovingly finished with 20 coats of hand-rubbed high-grade “piano gloss” lacquer. While the main body and baffling structure are built with MDF, the sculpted front baffle is formed from a dense, rigid and well-damped high-tech thermoset fiberglass resin composite material with integrated high-frequency acoustic waveguides. The speakers look to be almost floating as its curved bottom rests upon its sturdy aluminum base featuring large milled brass spikes with removable tips and integrated plastic feet for hard surfaces (and to aid in speaker placement). A masterpiece of design and love, crafted by those of us that care deeply about music and its reproduction in the home.

Manual
Hent manual til Aspen FR20

Color Options: Pearl White, Sable Black
Enclosure Type: Passive radiator (two, 10” side-firing passive radiators)
High Frequency Transducer: 2.5” planar magnetic with Teonex diaphragm
Mid Frequency Transducer: 10” planar magnetic with Teonex diaphragm
Low Frequency Transducer: 2 x 8” woofers, cast frame, carbon fiber Rohacell sandwich cone, 12lb advanced magnet structure
Crossover Frequency: 400 Hz, 2500 Hz – Linkwitz-Riley 4th order acoustic
Sensitivity (2.83V @ 1M): 87 dB
Nominal Impedance: 4 ohm (3.5 ohm minimum impedance)
Recommended Amplifier Power: 50-300W
Frequency Response: 23Hz-20kHz (-6dB) half space, 20 Hz (-6dB) in-room
Dimensions (HxWxD): 50.5” x 16” x 18.75″
Net Weight: 60.3 kg
