PS Audio P12 Power Plant

På lager
49.990 DKK
Leveringstid:3-4 uger

PS Audio P12 Power Plant er en særdeles vellydende Strømregenerator med 4 individuelle zoner/udtag. Præsterer 1500 VA ydelse med 3600 VA peak. Kølet med blæsere. 100% regenereret AC. Justerbar ydelse.

  • Gratis fragt over 500 DKK
  • Lagervarer sendes indenfor 24 timer
  • Afhentning i butik

PS Audio P12 Power Plant er en særdeles vellydende Strømregenerator med 4 individuelle zoner/udtag. Præsterer 1500 VA ydelse med 3600 VA peak. Kølet med blæsere. 100% regenereret AC. Justerbar ydelse.


Our most powerful compact AC regenerator, the P12 regenerates new, safe, and pure AC from your home's power outlets for breathtaking improvement.

The DirectStream Power Plant 12 takes your incoming AC power and regenerate new sine-wave-perfect, regulated high current AC power. In the process of regeneration any problems on your power line such as low voltage, distorted waveforms, sagging power and noise are eliminated. The results are both audibly and visually stunning when powering either audio or video products. Further, the level of protection afforded connected equipment is extraordinary. Feel 100% confident that a P12 will provide pure and safe power under any condition. Don’t starve your music or risk damaging your equipment. A P12 gives you greatly improved performance and safety from just plugging into the wall socket and far better dynamics, bass and a much bigger, open soundstage than any passive power conditioner on the market.

Design
The P12 takes your incoming AC power, converts it to DC, and then regenerates it, producing new sine-wave-perfect, regulated high current AC power. The input voltage to the P12 is fully protected by state-of-the-art clamping devices and the output is fully regulated, so even large voltage swings that would normally damage connected equipment are made safe by either clamping or regulating. The P12 PowerPlant features 8 outlets (US version) across 4 separate zones and delivers 1250 watts of pure, regenerated power to each receptacle through thick, copper busbars.

Application
In the process of regeneration, any problems on your power line, such as low voltage, distorted waveforms, and sagging power, are eliminated. With your system powered directly from the output of the P12, you can expect far better micro and macro dynamics, as well as cleaner, lower background noise. This is one of the most important pieces of audio equipment you can own, building a firm and reliable foundation for your system that will serve you for years to come.

Environment Specification
Location: Indoor use only
Duty Cycle: Suitable for continuous operation
Moisture Sensitivity: Not sealed against moisture
Operating Humidity: <80%rh
Storage Temperature: -40C to +40C
Operating Temperature: 0C to 40C
Max Operating Altitude: 12,000’ (3500m)
Electrical Supply Nominal Rating: 230V 10A 50/60Hz

Instrument Specification
Unit Dimensions: 43cm W x 36cm D x 10.16 cm H
Unit Weight: 16.7 kg
Shipping Weight: 21.7 kg
Nominal Input Voltage: 200 –285VAC
Maximum Continuous Load: 1200VA
Maximum Peak Load (30 seconds): 3800VA
Voltage Regulation: 1V
Output Distortion (Resistive Load): <0.9%
Output Distortion (Reactive Load): <0.9% / 0.1% typical
Output Impedance: <0.008 ohm
Noise Reduction: 100kHz – 2MHz >80dB
Efficiency @1200 VA: >85%
Input Frequency: 45 – 65 Hz
Under Voltage Limit: Continuous -10% of setting 15 sec duration -15% of setting
Over Voltage Limit: Continuous 5% of setting 15 sec duration 10% of setting
Energy Dissipation: 1270J
Peak Current Surge: 90,000A
Max Surge Voltage: 6,000V
Clamp Level: 800V
DC Trigger Configuration: Tip Positive
DC Trigger Voltage: 5 – 15Vdc

Download manual
