The Gryphon Diablo 333 Reference DAC3 modul

DAC3 er den perfekte makker til den nye Diablo 333 integrerede forstærker og tilføjer fem digitale indgange i topklasse til Diablo 333's allerede eksisterende fire analoge indgange.

Med det indbyggede DAC3-modul viser Diablo 333-displayet information om den valgte digitale indgang, samplingfrekvens, PCM/DSD-format og indstillingen for det digitale filter.

Features

- True Dual Mono discrete build Class A Analog configuration
- Zero global negative feedback
- Sabre High-Performance ES9039PRO D/A converter
- USB input compatible with following audio formats via PC/MAC/Linux: PCM: 44.1, 48, 88.2, 96, 176.4, 192, 352.8 and 384 kHz, up to 32 bits DSD via USB: DSD64, DSD128, DSD256 and DSD512
- XLR and BNC inputs compatible with PCM: 22.05, 24, 32, 44.1, 48, 64, 88.2, 96, 176.4 and 192 kHz, up to 32 bits
- TOSLINK input compatible with PCM: 22.05, 24, 32, 44.1, 48, 64, 88.2, 96 kHz, up to 24 bits
- Seven user-selectable PCM digital roll-off filters
- Temperature-compensated, ultra-low jitter crystal oscillator with better than 5 parts per million accuracy
- Super-Capacitor (12.5 Farad!) power supply for USB module – acts like a true battery supply
- First-order PCM analogue filters and second-order DSD analogue filters with Polypropylene capacitors
- Analogue output stages with ultra-low noise +/- 22VDC regulated voltage supplies for best analogue THD and noise suppression
- Multiple Local Voltage regulators for best digital noise suppression
- Separate left/right channel ultra-low noise power supply for analogue section of ES9039PRO DAC
- Ultra-short signal path
- Minimal internal wiring
- Six-layer printed circuit boards
- PCB-mounted input sockets eliminate wiring and shorten signal path
- Gold-plated Neutric XLR socket for one balanced 110Ω AES source
- Gold-plated 75Ω BNC sockets with Teflon insulation for 2 S/PDIF sources
- One TOSLINK optical fiber input
- Designed and built in Denmark
