Vertere MG-1 Magic Groove Mk II, SG-1 PTA tonearm, Tempo motorstyring

På lager
110.000  DKK
Leveringstid:1-2 uger

Vertere MG-1 Magic Groove Mk II pladespiller som tager vinylafspilning videre end hvad der normalt er muligt i denne klasse. Denne pladespiller omfatter og deler væsentlige designelementer fra den væsentlig mere bekostelige SG-1.

  • Gratis fragt over 750 DKK
  • Lagervarer sendes indenfor 24 timer
  • Afhentning i butik

Vertere MG-1 Magic Groove Mk II pladespiller som tager vinylafspilning videre end hvad der normalt er muligt i denne klasse. Denne pladespiller omfatter og deler væsentlige designelementer fra den væsentlig mere bekostelige SG-1.

Et enestående design, MG-1 Magic Groove Mk II pladespilleren byder på forrygende ydelse som kun overgåes af referencemodeller. Som med alle Vertere pladespiller, er hver enkel komponent bygget til Custom-niveau, med de bedste materialer og den største præcision.

Hvorfor købe en Vertere MG-1 Magic Groove Mk II?

- Et perfekt match til Vertere SG-1 PTA tonearmen, enestående bygget og en fornøjelse at betjene.
- Spiller musik med den forventede følelse og ægte dynamik, blot derhjemme.
- Byder på en ideel platform til at opgradere tonearm, kabler og pickup.

Leveres i en pakkeløsning omfattende plint og Tempo motorstyring, Super Groove SG-1 PTA tonearm, Redline signalkabel og Technomat plademåtte. Kan endvidere konfigureres på anden vis. Kontakt os venligst for rådgivning.


Main bearing assembly: The MG-1 MkII main bearing is directly derived from the SG‐1 utilising exactly the same bearing spindle and ball with a phosphor bronze bearing housing machined using the same precision engineering techniques to our high standards. The materials used and manufacturing to extreme engineering tolerances make the MG-1 MkII main bearing silent, smooth running and second only to the SG-1. MG‐1 MkII main bearing is lubricated with Vertere proprietary formulated L‐1G record player main bearing oil for ultimate longevity.

Record player motor assembly: Directly derived from the RG-1 and SG-1 motor assembly design, the MG-1 MkII utilises double precision bearings fitted to its dedicated Acetal motor platform and motor bearing support. The motor is aligned using three spike pointed screws making the perfect residual vibration coupling of the motor to the platform itself. This unique design keeps the motor continuously synchronous to provide a drive with constant belt tension. Simply put, it drives the platter at constant speed without variation. As a finishing touch is the switchable internal mood lighting.

Main platter: Record player motor assembly Directly derived from the RG-1 and SG-1 motor assembly design, the MG-1 MkII utilises double precision bearings fitted to its dedicated Acetal motor platform and motor bearing support. The motor is aligned using three spike pointed screws making the perfect residual vibration coupling of the motor to the platform itself. This unique design keeps the motor continuously synchronous to provide a drive with constant belt tension. Simply put, it drives the platter at constant speed without variation. As a finishing touch is the switchable internal mood lighting.

Tempo Motor Drive: It is absolutely critical that the record player motor is powered and controlled faultlessly to ensure a full and musical performance of the record player. The Tempo Motor Drive has new enhanced circuitry for speed accuracy, power delivery. The MkIII utilises two fully protected output power devices with much improved control of the motor. The new output circuit provides the platter with constant and smoother drive. Added for ease of use are three motor noise-eliminating pots, now accessible from the underside of the unit. Elegant and simple to use with a ‘super charged’ engine under its bonnet!

Special Metallic Finishes: Vertere Special Metallic Black, Pearlescent White & Champagne finishes are now available for the SG-1 record player at a premium. Following in the footsteps of the RG-1, these lustrous, vibrant colours provide perfect alternatives to the original Clear finish of the SG-1. Clear cast acrylic was carefully selected for SG-1’s plinth material as it provides the most stable and acoustically suitable platform for all its critical components. The specially formulated paint and method of printing of these glistening finishes enhance the aesthetics without any compromise in performance of the SG-1 record player. The Vertere emblem printed on the top plinth adds the final finishing touch.

Tempo Motor Cover: The elegant silver anodised Tempo Motor Cover is machined from solid aluminium alloy. It makes accessibility and placement of the drive belt easy and a delight to use. The cover also acts as a diffuser for the two illuminating LED lights, within the MG-1 MkII Record Player, complementing its stunning looks. Simple, elegant, beautiful.

MG-1 Magic Groove Record Player

Type
Belt drive

Motor
24 Pole Synchronous
Spindle Support Acetal Ball Bearing

Motor Mount
Acetal Mount & Bearing – Two Articulated
Ball Race Bearings with 3-point Adjustable

Pulley
Super Precision Aluminium Alloy

Drive Belt
Precision Ground Polymer

Platter MG-1
Single Piece Super Precision Aluminium Alloy
3mm Bonded Acrylic Record Interface

Bearing Spindle MG-1
Precision Hardened Stainless Steel
Roundness / Concentricity and Finish < 2 Micron

Bearing Spindle MG-1
Precision Hardened Stainless Steel
Roundness / Concentricity and Finish < 2 Micron

Bearing Housing MG-1
High Copper Content Phosphor Bronze
Clearance < 6.0 Microns

Plinth Structure
20mm Clear Cast Acrylic with optional finishes
Special Metallic Black or Metallic Pearlescent White and Metallic Champagne
With switchable internal illumination

Isolation System
2 Stage Compliant and 1 Stage Rigid
9 De-coupler Sets and Aluminium Alloy/SS Feet & Felt

Motor Drive P/S
Microprocessor Controlled & Programmable
33.3 and 45 rpm (<0.2%)

Wow and Flutter
<0.1%

Rumble
<-85dB

Dimensions (W x D x H)
468 x 384 x 140-155mm

Weight
14 Kg
