Soulnote E-2 v2 Phono
Soulnote E-2 v2 Phono Equalizer, fuldt balanceret RIAA sågar med optisk indgang til DS Audio pickupper. Forgængeren E-2 var fantastisk, denne version 2 er endnu bedre.
- Gratis fragt over 750 DKK
- Lagervarer sendes indenfor 24 timer
- Afhentning i butik
• Dedicated Optical Cartridge Input
The E-2 VER2 features the same XLR connector for separated power supply cables as employed in the E-3, maximizing the unique advantages of optical cartridges.
• Advanced Analog Circuit for Optical Cartridges
The fully balanced, non-NFB “New Type-R” (*) circuit from the E-3 has been directly implemented, ensuring uncompromising fidelity and musical expression.
• Refined MC/MM Circuit
The MC/MM stages have been significantly simplified with a newly designed bias circuit, achieving a notable improvement in sound quality and overall performance.
• Enhanced Chassis design
The unfixed top cover, also adopted in the A-2 VER2, has been further refined to contribute to sonic purity and resonance control.
• Extended Flexibility
MC loading is now supported up to 1 kΩ, offering greater compatibility with a wide range of cartridges. Furthermore, all of the original’s versatile features, including adjustable EQ curve functionality, have been fully retained.
Input sensitivity: MC: 0.4 mV, MM: 5 mV, OPT: 70 mV
Gain: MC: 77 dB, MM: 55 dB, OPT: 32 dB
Rated output: BALANCED: 3.0 V, UNBALANCED: 1.5 V
RIAA deviation: ±0.2 dB
MC load resistance: 3 Ω, 10 Ω, 30 Ω, 100 Ω, 300 Ω, 1 kΩ
MM load capacitance: 100 P, 200 P, 350 P
MM load resistance: 47 kΩ
Equalizer frequency:
- ROLL-OFF [kHz]: 1.59, 2.12 (RIAA), 2.59, 3.18, 6.89, FLAT
- TURNOVER [Hz]: 250, 390, 500 (RIAA), 630
- LOW LIMIT [Hz]: 50 (RIAA), 71, 100, 125, 150, FLAT
Power voltage: 230V AC 50Hz
Power consumption: 29W
Dimensions: 430 (W) × 160 (H) × 410 (D) mm
Weight: Approximately 20 kg
Included accessories: Spikes, Power cord
